This valve is used as a remote control valve for pressure control valves.
These valves are used in a hydraulic circuit to prevent damage due to excess pressure and to adjust the max. Pressure of small capacity. Available sizes NG6 & NG10.
| Max flow | Working Max Pressure |
| 4 to 120 lpm | 250 bar |
Pilot Operated Relief Valve /Solenoid Controlled Relief valves
These valves protect the hydraulic system from excessive pressure, and can be used to maintain constant pressure in a hydraulic system. Remote control and unloading are permitted by vent circuits.
Solenoid Controlled Relief valves These valves are a combination of relief valve and solenoid valve. Piping between the two is eliminated as the solenoid valves is directly mounted on the relief valve and connected with the relief valve vent. Pump pressure may be unloaded remotely by an electrical signal to the solenoid, or by connecting pilot relief valves to the solenoid valve ports
| Max flow | Working Max Pressure |
| 100 to 400 lpm | 0 to 250 bar |
Pressure reducing valves are used to set the pressure of a hydraulic circuit below that of the main circuit. Operation under remote control is also possible by using the remote control port.
Pressure Reducing and Check Valves Pressure reducing and check valves are used to set the pressure of a hydraulic circuit below that of the main circuit. They have check valves, which allow a free flow from the secondary side to the primary. Operating under remote control is also possible by using the remote control port.
| Max flow | Working Max Pressure |
| 7 lpm to 250 lpm | 7 to 250 bar |
Unloading relief valves are used to operate pumps under a minimum load in accumulator or 2-pressure pump circuits etc.
| Max flow | Working Max Pressure |
| 1 lpm to 125 lpm | 25 to 210 bar |
H Type Pressure Control Valves These valves are hydraulically damped, direct operated, pressure control valves which can be actuated by internal or external pilot pressure. There are various types of valve including sequence, unloading and low pressure relief valves, all of which are operated by a pressure rise in the circuit, sensed either internally or remotely.
| Max flow | Working Max Pressure |
| 1 lpm to 250 lpm | 2.5 to 210 bar |
